00MY813 - Lenovo Brocade 6505 Fiber Channel SAN Switch

1. Ports: 24 ports (8 Gbps)
2. Switching capacity: 384 Gbps
3. Latency: 700 ns
4. Buffer credits: 8192
5. Supported protocols: FC-AL, FC-FLA, FC-FG, FC-GS-2, FC-PH, FC-PH-2, FC-PH-3, FC-PLDA, FC-SB-2, FC-SW-2, FC-SW-3, FC-Tape, FC-VI, FCP, FCP-2, FCP-3, FC-SP, FC-BB-2, FC-BB-3
6. Management: CLI, SNMP, Telnet, HTTP, SMI-S, Brocade Web Tools, Brocade Network Advisor
7. Power supply: 2 hot-swappable AC or DC power supplies
8. Power consumption: 110W maximum
9. Operating temperature: 0°C to 40°C (32°F to 104°F)
10. Humidity: 10% to 85% non-condensing
11. Dimensions: 1.7" x 16.9" x 12.5"
12. Weight: 10.8 lbs

Notes:
1. Supports up to 500,000 IOPS and 4,000 device logins.
2. Provides advanced diagnostics and troubleshooting capabilities.
3. Offers simplified deployment and configuration with Brocade EZSwitchSetup.
