SGI 060-0107-001 | 2.5V DC Voltage Regulator Module

1. Input Voltage Range: 3.0V to 5.5V
2. Output Voltage Range: 2.5V ± 2%
3. Output Current: 150mA
4. Dropout Voltage: 150mV
5. Quiescent Current: 50µA
6. Operating Temperature Range: -40°C to +85°C
7. Load Regulation: 0.1%/mA
8. Line Regulation: 0.05%/V
9. Ripple Rejection: 75dB
10. Thermal Shutdown Protection
11. Short Circuit Protection
12. Package Type: SOT-23

Helpful Notes:
1. This voltage regulator module is suitable for low power applications.
2. The SOT-23 package is small and allows for easy integration into a circuit board.
3. The thermal shutdown and short circuit protection features help to prevent damage to the module and other components in the circuit.
