Cisco 15454-Ad-1c Optical Filter Card

1. Dimensions: 1.38 x 16.0 x 9.25 in.
2. Weight: 2.0 lbs
3. Operating Temperature: -40 to 65°C (-40 to 149°F)
4. Storage Temperature: -40 to 85°C (-40 to 185°F)
5. Optical Connector Type: SC/APC
6. Wavelength Range: 1528.77 to 1568.77 nm
7. Insertion Loss: 4.0 dB typical, 5.0 dB maximum
8. Return Loss: 50 dB typical, 40 dB minimum
9. Polarization Dependent Loss: 0.5 dB typical, 0.75 dB maximum
10. Maximum Input Power: 23 dBm
11. Minimum Input Power: -20 dBm
12. Maximum Output Power: 17 dBm

Notes:
1. The Cisco 15454-AD-1C Optical Filter Card is designed for use in dense wavelength-division multiplexing (DWDM) systems.
2. The card provides a 50 GHz channel spacing and a 100 GHz channel spacing option.
3. The card is hot-swappable, allowing for easy installation and replacement without disrupting network operations.
