17401RU - IBM TotalStorage EXP700 Expansion Unit

1. Capacity: Up to 14 disk drives
2. Disk Interface: Ultra320 SCSI
3. Supported Drives: 3.5-inch hot-swap, 1-inch high, 10K or 15K rpm Ultra320 SCSI disk drives
4. Maximum Capacity: 1.68 TB (using 14 x 146 GB disk drives)
5. RAID Levels: 0, 1, 3, 5, and 10
6. Power Supply: Dual redundant, hot-swappable power supplies
7. Cooling: Dual redundant, hot-swappable cooling fans
8. Dimensions: 3.4 x 19 x 23.5 inches (H x W x D)
9. Weight: 65 lbs (without disk drives)
10. Expansion Slots: 2 x Ultra320 SCSI expansion ports
11. Operating Temperature: 10°C to 35°C (50°F to 95°F)
12. Operating Humidity: 20% to 80% non-condensing relative humidity

Notes:
1. The IBM TotalStorage EXP700 Expansion Unit is designed to provide additional storage capacity for IBM servers.
2. The unit supports a wide range of RAID levels, providing flexibility in data protection and performance.
3. With its hot-swappable components, the EXP700 is designed for high availability and easy maintenance.
