2280800-R - Adaptec 7805H Single 6Gb/s PCI Express 3.0 X8 SAS/SATA Controller

1. Interface Type: PCIe 3.0 x8
2. Data Transfer Rate: 6 Gb/s
3. RAID Levels: RAID 0, 1, 1E, 5, 6, 10, 50, 60
4. Supported Devices: SAS/SATA
5. Max Storage Devices Qty: 256
6. Processor: PMC-Sierra PM8015
7. Cache Memory Size: 1GB
8. Form Factor: Plug-in Card
9. OS Support: Windows, Linux, VMware
10. Dimensions (WxDxH): 6.6 in x 2.5 in
11. Weight: 0.22 lbs
12. Power Consumption: 11.5 Watt (Max)

Notes:
1. Adaptec maxView Storage Manager software provides a web interface and command-line interface to configure and manage the RAID controller.
2. The Adaptec 7805H supports hot-swap functionality, allowing for easy replacement of failed drives without shutting down the system.
3. This controller offers advanced data protection features such as RAID-level migration and capacity expansion, allowing for easy scalability.
