30YMH - Dell PowerEdge R520 CTO Chassis

1. Processor Support: Intel Xeon E5-2400 and E5-2400 v2 processors
2. Memory: Up to 768GB (24 DIMM slots) DDR3 up to 1866MT/s
3. Storage: Up to 8 x 3.5" SAS/SATA (HDD/SSD) max 32TB or up to 16 x 2.5" SAS/SATA (HDD/SSD) max 16TB
4. RAID Controller: PERC S110, PERC H310, PERC H710, PERC H710P
5. Network Controller: Broadcom 5720 Quad Port 1GbE BASE-T (optional add-in NICs)
6. Expansion Slots: 2 PCIe slots (One x8 and One x16)
7. Power Supply: Dual, Hot-plug, Redundant Power Supply (1+1), 495W, 750W, 1100W
8. Management: iDRAC7 with Lifecycle Controller
9. Form Factor: 2U Rack Chassis
10. Operating System Support: Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
11. Front Ports: 2 x USB 2.0, 1 x Video, 1 x Serial
12. Rear Ports: 2 x USB 2.0, 1 x Video, 1 x Serial, 4 x RJ-45 including 2 x GbE LOM

Notes:
1. The PowerEdge R520 is a reliable and scalable server suitable for small and medium-sized businesses.
2. It offers flexible storage options and supports a wide range of operating systems.
3. The iDRAC7 with Lifecycle Controller enables remote management and monitoring of the server.
