HP 405625 001 | PCI Express Quad Port SAS/SATA 3GB/s RAID Controller Host Bus Adapter

Here are 12 technical specifications for the HP PCI Express Quad-Port SAS/SATA 3GB/s RAID Controller Host Bus Adapter:

1. Interface Type: PCI Express x8
2. Controller Interface Type: Serial ATA-300 / SAS
3. Data Transfer Rate: 300 MBps
4. RAID Level: RAID 0, RAID 1, RAID 5, RAID 10, RAID 50
5. Number of Ports: 4
6. Processor: LSI LSISAS1068E
7. Cache Memory: 256 MB
8. Supported Devices: Hard drive, disk array (RAID)
9. OS Required: Microsoft Windows Server 2003, Red Hat Enterprise Linux 4, SuSE Linux Enterprise Server 10, Microsoft Windows Server 2008
10. Dimensions (WxDxH): 6.6 in x 2.5 in
11. Weight: 0.44 lbs
12. Designed For: ProLiant DL120 G5, DL120 G6, DL160 G5, DL160 G5p, DL160 G6, DL165 G5, DL165 G5p, DL165 G6, DL180 G5, DL185 G5, DL320 G5, DL320 G5p, DL320 G6, DL320s, DL370 G6, DL380 G6, DL385 G5p, DL385 G6, DL580 G5, DL585 G5, DL585 G6, ML110 G5, ML110 G6, ML115 G5, ML150 G5, ML150 G6, ML310 G5, ML350 G5, ML350 G6, ML370 G6, SL160s G6, SL170s G6, SL2x170z G6, SL2x170z G6 (base), SL2x170z G6 (performance), SL390s G6

Helpful notes:
1. This adapter supports up to 4 SAS or SATA drives and provides hardware RAID for improved performance and data protection.
2. The included cache memory helps to improve overall system performance by reducing the number of disk operations required.
3. This adapter is compatible with a wide range of HP ProLiant servers, making it a versatile and reliable choice for many different applications.
