Compaq 412329-001 | System Board for Proliant ML570 G3 Server

Technical Specifications:
- Processor Socket Type: Socket 604
- Supported Processors: Intel Xeon
- Chipset Type: Intel E7520
- Max Supported Memory: 64 GB
- Memory Slots: 16 x 240-pin DIMM
- Memory Speed Supported: PC2-3200, PC2-4300
- Expansion Slots: 6 x PCI-X, 2 x PCI-E x8
- Integrated Graphics: ATI RAGE XL
- Integrated Network: Dual Gigabit Ethernet
- RAID Support: RAID 0, 1, 1+0, 5
- USB Ports: 2 x USB 2.0
- Power Connectors: 1 x 24-pin ATX, 1 x 8-pin EPS

Helpful Notes:
- This system board is compatible with Proliant ML570 G3 servers only.
- It supports up to 16 dual-rank DIMMs for a maximum memory capacity of 64 GB.
- The integrated ATI RAGE XL graphics controller supports resolutions up to 1600x1200 at 8 bits per pixel.
