4203616L1#ATM - AdTran Total Access 616 (T1 ATM) Gateway

Here are the technical specifications for AdTran Total Access 616 (T1 ATM) Gateway:

1. Dimensions: 1.75 x 12.25 x 7.5 inches
2. Weight: 3.5 lbs
3. Interfaces: 1 x T1 ATM WAN, 1 x 10/100Base-T Ethernet LAN
4. Protocols: PPP, Frame Relay, MLPPP, MLFR, IP, TCP, UDP, ICMP, HTTP, SNMP, Telnet, SSH, TFTP
5. Voice protocols: G.711, G.729a, G.723.1, T.38
6. Voice features: Caller ID, call waiting, call forwarding, call transfer, 3-way conferencing, voice activity detection, echo cancellation
7. Data rate: Up to 1.5 Mbps
8. Power consumption: 7 watts
9. Operating temperature: 0°C to 50°C
10. Storage temperature: -20°C to 70°C
11. Humidity: Up to 95% non-condensing
12. Certifications: FCC Part 15 Class A, UL 60950, CSA C22.2 No. 60950, CE

Helpful notes:
1. The AdTran Total Access 616 (T1 ATM) Gateway is a versatile device that supports both voice and data applications.
2. With its compact size and low power consumption, it is ideal for small businesses or remote offices.
3. The device is easy to set up and manage, with a user-friendly web interface and support for remote management protocols like SNMP and SSH.
