4212924L2 - AdTran Total Access 924 FXS & FXO Gateway

Here are 12 technical specifications for the AdTran Total Access 924 FXS & FXO Gateway:

1. Dimensions: 8.5" x 17.25" x 1.72"
2. Weight: 5.5 lbs
3. Power: 100-240 VAC, 50/60 Hz, 1.5A max
4. Operating temperature: 0°C to 50°C
5. Storage temperature: -20°C to 70°C
6. Humidity: Up to 95% non-condensing
7. Interfaces: 24 FXS ports, 4 FXO ports, 2 10/100Base-T Ethernet ports, 1 USB port, 1 console port
8. Protocols: SIP, MGCP, SCCP, H.323
9. Voice codecs: G.711, G.729a, G.726, G.723.1, G.722
10. QoS: DiffServ, TOS, 802.1p/q VLAN tagging
11. Management: Web-based GUI, CLI, SNMP, Telnet, SSH, TFTP, FTP, HTTP/HTTPS
12. Security: HTTPS, SSH, TLS, SRTP, ACLs, SIP authentication

Helpful notes:
1. The Total Access 924 supports up to 24 analog phones or fax machines.
2. The 4 FXO ports allow for connection to a PSTN or PBX for failover or local calling.
3. The gateway can be configured for both voice and data applications.
