Dell 503M7 | Mixed Use 960 GB SAS 12Gbs 512n 2.5-inch Hot-plug Solid State Drive PX05SV

TECHNICAL SPECIFICATIONS:

1. Capacity: 960 GB
2. Form Factor: 2.5-inch
3. Interface: SAS 12Gb/s
4. Drive Type: Solid State Drive (SSD)
5. NAND Flash Type: MLC (Multi-Level Cell)
6. Data Transfer Rate: Up to 12 Gbps
7. Drive Interface: SAS
8. Drive Features: Hot-plug support, End-to-end data protection, Power loss protection, T10 Protection Information (T10-PI)
9. Drive Width: 2.5 inches
10. Drive Height: 0.6 inches
11. Compatibility: Dell PowerEdge servers and storage systems
12. Power Consumption: Idle: 4.7W, Operating: 7.0W (average), Peak: 11.1W
13. MTBF (Mean Time Between Failures): 2 million hours
13. Endurance: 3 drive writes per day (DWPD) for 5 years
14. Operating Temperature: 0°C to 55°C (32°F to 131°F)
15. Storage Temperature: -40°C to 70°C (-40°F to 158°F)
16. Vibration Tolerance: 2.17 Grms (5-700 Hz) in operation, 3.13 Grms (5-800 Hz) non-operational
17. Shock Tolerance: 1,000 G (0.5ms) half sine wave
18. Dimensions (W x D x H): 2.75 x 3.96 x 0.59 inches (69.85 x 100.58 x 14.99 mm)
19. Weight: 0.20 lbs (0.09 kg)
