HP 517604-001 | DC04 Core Switching Blade

1. Brand: HP
2. Model: DC04 Core Switching Blade
3. Device Type: Switch - 16 ports - L3 - managed
4. Enclosure Type: Plug-in module
5. Subtype: 10 Gigabit Ethernet
6. Ports: 16 x 10 Gigabit SFP+
7. Performance: Switching capacity: 320 Gbps, Throughput: 238 Mpps
8. Routing Protocol: OSPF, BGP-4, IS-IS, RIP-1, RIP-2, IGMP, VRRP, PIM-SM, static IP routing, PIM-DM, IGMPv3, GRE, OSPFv3, PIM-SSM, Multiprotocol BGP, MSDP, static IPv4 routing, static IPv6 routing, ECMP
9. Remote Management Protocol: SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS, CLI
10. Features: Flow control, layer 3 switching, layer 2 switching, DHCP support, ARP support, VLAN support, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, Weighted Round Robin (WRR) queuing, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, SNTP support, sFlow, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, MLD snooping, STP Root Guard, LLDP support, Link Aggregation Control Protocol (LACP), Energy Efficient Ethernet, dual firmware images, Strict Priority Queuing (SPQ), Class of Service (CoS), Generic Attribute Registration Protocol (GARP), Generic VLAN Registration Protocol (GVRP), Type of Service (ToS), DiffServ Code Point (DSCP) support, 802.1x authentication, VLAN Double Tagging (Q-in-Q), Internet Control Message Protocol (ICMP), IGMP querier, IGMP Fast Leave, Virtual Routing and Forwarding (VRF), Management Information Base (MIB), Neighbor Discovery Protocol (NDP), Bidirectional Forwarding Detection (BFD), Virtual Extensible LAN (VXLAN)
11. Power Consumption Operational: 100 Watt
12. Dimensions (WxDxH): 14.4 in x 16.5 in x 1.2 in

Notes:
1. This switch blade offers high-performance, low-latency networking for data center applications.
2. The DC04 Core Switching Blade is designed to provide scalable and resilient connectivity for demanding enterprise environments.
3. With its advanced features and robust design, this switching blade is an ideal solution for organizations that require high-speed, high-capacity networking.
