9300-16I - LSI Logic 9300-16i 12gbs 16-Port PCI-Express 3.0 X8 SAS Controller

Key Features :
Host Bus Type : X8 Lane Pci Express® 3.0
Physical Dimensions : 4.4 X 6.1
Internal Ports : 16
Cable Support : passive Copper, Active Optical
Data Transfer Rates : 12gb/s Sas 3.0 Compliant
Devices Supported : 1024 Non-raid Sata/sata Devices Per Controller
Fusion Mpt Support : fusion Mpt™ 2.5
I/o Controller : 2 Sas 3008
Internal Connectors : 4 Mini-sas Hd Sff8643
Mtbf : >2,500,000 Hours
Operating Humidity : 5% To 90% Non-condensing
Operating Temperature : 0°c To 55°c
Operating Voltage : +12v +/-8% 3.3v +/-9%
Pci Power : 27w
