9400-16I | Broadcom 12Gb/s SAS/SATA/NVME Tri-Mode PCI-E HBA -

Key Features :
Host Bus Type X8 Lane Pci Express® 3.1
Devices Supported Sas/sata: 1024, Nvme: 24
Internal Connectors 4 Mini-sas Hd X4 Sff-8643
Internal Ports 16
Operating Temperature 10° To 55° C
Operating Voltage +12v +/-8%, 3.3v +/-9%
Os Support Microsoft Windows, Linux, Vmware.
Pci Power Typical: 11.95w
Cable Support Passive Copper
I/o Controller Sas3416
Mtbf > > 4,500,000 Hours At 40° C
Operating Humidity 20% To 80% Non-condensing
Data Transfer Rates 12 Gb/s Sas-3 And 8 Gt/s Pcie Gen 3 (nvme) Compliant
Physical Dimensions Low Profile 6.127” X 2.712”
