ASR-5445 - Adaptec 8-Port 512MB SAS / SATA Controller

1. Interface Type: PCI Express x8
2. Data Transfer Rate: 6 Gbps
3. RAID Levels: 0, 1, 10, 5, 50, 6, 60, JBOD
4. Supported Devices: SAS/SATA
5. Number of Ports: 8
6. Cache Memory Size: 512 MB
7. Processor: PMC-Sierra PM8013 Dual Core RAID on Chip (ROC)
8. Form Factor: Low Profile MD2
9. Operating Temperature: 0°C to 55°C
10. Operating Humidity: 5% to 90%
11. OS Support: Windows, Linux, VMware, Solaris
12. Power Consumption: 11.5W

Notes:
1. The Adaptec RAID Code (ARC) delivers maximum reliability with RAID levels 0, 1, 10, 5, 50, 6, 60, and JBOD.
2. The controller supports up to 256 SAS/SATA devices using SAS expanders.
3. The Adaptec maxView Storage Manager software provides a web-based interface that allows you to configure, monitor, and maintain the controller.
