DL-6505-24-16G-0R - Brocade 6505 24 Active Ports 16Gb FC SFP+ SAN Switch

Here are 12 technical specifications for the Brocade 6505 SAN Switch:

1. Port Speed: 16 Gbps
2. Number of Ports: 24
3. Form Factor: Rack-mountable
4. Fibre Channel Class Support: Class 2, Class 3, Class F
5. Maximum Frame Size: 2112 bytes
6. Buffer Credits: 8192
7. Power Supply: Dual redundant, hot-swappable
8. Power Consumption: 130W (typical)
9. Operating Temperature: 0°C to 40°C (32°F to 104°F)
10. Storage Temperature: -25°C to 70°C (-13°F to 158°F)
11. Humidity Range: 10% to 85% non-condensing
12. Dimensions (HxWxD): 1.7 x 16.8 x 12.5 in.

Helpful notes:
1. The Brocade 6505 SAN Switch is a high-performance, low-latency switch designed for enterprise-level storage networks.
2. The switch supports a variety of diagnostic and management features, including port mirroring, SNMP, and RADIUS authentication.
3. The Brocade 6505 SAN Switch is compatible with a wide range of SFP+ transceivers, allowing for flexible connectivity options.
