DS1402003 - Avaya Nortel 8003 3 Slot Chassis

1. Dimensions: 17.3 x 13.8 x 3.5 inches
2. Weight: 12.1 pounds
3. Power supply: AC 100/240 V (50/60 Hz)
4. Maximum power consumption: 300 W
5. Operating temperature: 0°C to 40°C (32°F to 104°F)
6. Cooling system: 2 fans
7. Expansion slots: 3 slots for media modules
8. Supported media modules: Ethernet, Fast Ethernet, Gigabit Ethernet, ATM, Token Ring, FDDI, and WAN protocols
9. Management interface: RS-232 serial port, Ethernet port
10. Supported protocols: SNMP, Telnet, HTTP, RMON, CLI
11. Redundancy: Supports redundant power supply and control modules
12. Compatibility: Compatible with Avaya/Nortel BayStack 450, 470, 5000, and 5500 series modules.

Notes:
1. The chassis is designed for high-performance networking applications and can support a wide range of media modules.
2. The redundant power supply and control modules provide added reliability and uptime for critical applications.
3. The management interface allows for easy configuration and monitoring of the chassis and attached modules.
