Avaya DS1404093 | Nortel Ethernet Routing Switch 8348GTX Module

Here are 12 technical specifications for the Avaya Nortel Ethernet Routing Switch 8348GTX Module:

1. Switching capacity: 176 Gbps
2. Forwarding rate: 131 Mpps
3. Number of ports: 48 Ethernet 10/100/1000 ports and 4 SFP+ 10 Gigabit Ethernet ports
4. Power over Ethernet (PoE) support: No
5. VLAN support: Yes, up to 4,096 VLAN IDs
6. Quality of Service (QoS) support: Yes, with 8 priority queues per port
7. Spanning Tree Protocol (STP) support: Yes, including Rapid Spanning Tree Protocol (RSTP) and Multiple Spanning Tree Protocol (MSTP)
8. Link Aggregation Control Protocol (LACP) support: Yes, with up to 32 groups and 8 ports per group
9. Jumbo frame support: Yes, up to 9,216 bytes
10. Management interface: CLI, web-based GUI, SNMP, and RMON
11. Redundancy support: Yes, with redundant power supplies and fans
12. Dimensions (HxWxD): 1.73 x 17.4 x 16.1 inches

Helpful notes:
1. The Avaya Nortel Ethernet Routing Switch 8348GTX Module is designed for high-performance data center and enterprise network applications.
2. The switch supports advanced features such as IPv6 routing, Layer 3 switching, and Access Control Lists (ACLs).
3. The 4 SFP+ 10 Gigabit Ethernet ports provide high-speed connectivity for uplink or stacking purposes.
