Avaya DS1405E01 | Nortel 8001Ps Power Supply

Here are 12 technical specifications for the Avaya Nortel 8001Ps Power Supply:

1. Input Voltage: 100-240V AC, 50/60 Hz
2. Output Voltage: 48V DC
3. Output Power: 675W
4. Efficiency: 80% typical
5. Operating Temperature: 0°C to 50°C
6. Storage Temperature: -40°C to 85°C
7. Operating Humidity: 5% to 95% non-condensing
8. Dimensions: 1.7 x 3.2 x 10.5 inches
9. Weight: 2.2 pounds
10. AC Input Connector: IEC 320-C14
11. DC Output Connector: 2-pin terminal block
12. Protections: Overvoltage, overcurrent, short circuit

Helpful notes:
1. The Avaya Nortel 8001Ps Power Supply is designed for use with the Ethernet Routing Switch 8600 series.
2. This power supply is hot-swappable, allowing for replacement without powering down the switch.
3. The 2-pin terminal block connector on the DC output allows for easy installation and maintenance.
