Dell JD098 | PERC 5/i PCI Express SAS 3Gb/s Controller (Single Connector/ Non RAID) for PowerEdge 1950 / 2950

Here are the technical specifications for the Dell PERC 5/i PCI Express SAS 3Gb/s Controller:

1. Interface Type: PCI Express
2. Data Transfer Rate: 3 Gb/s
3. Supported Devices: Hard drive, tape drive, disk array (RAID)
4. RAID Levels: 0, 1, 5, 10, 50
5. Buffer Size: 256 MB
6. Number of Connectors: 1
7. Supported Operating Systems: Microsoft Windows, Red Hat Linux, SuSE Linux, VMware ESX
8. Dimensions (WxDxH): 6.6 cm x 16.8 cm x 1.5 cm
9. Weight: 68 g
10. Power Consumption: 8.5 W
11. Compatible with: Dell PowerEdge 1950, 2950
12. Part Number: JD098

Helpful Notes:
1. The Dell PERC 5/i controller supports SAS and SATA hard drives, but cannot mix them in the same RAID array.
2. The controller can be used in non-RAID mode to simply add additional hard drive capacity to a server.
3. This is a clean pull item, meaning it has been removed from a working server and tested to ensure functionality.
