L3-25413-04B | LSI 9266-4i SGL 6Gb/s Quad Port Internal PCI-E SATA/SAS RAID Controller with 1GB DDR-III Cache Memory

Here are the technical specifications for the LSI 9266-4i SGL RAID Controller:

1. Interface Type: PCI Express 2.0 x8
2. Data Transfer Rate: 6 Gb/s per port
3. RAID Levels: 0, 1, 5, 6, 10, 50, 60
4. Cache Memory: 1GB DDR-III
5. Supported Devices: SAS/SATA
6. Max Storage Devices Quantity: 128
7. Processor: LSISAS2208 Dual-Core RAID on Chip (ROC)
8. Form Factor: Low Profile
9. Operating Temperature: 0°C to 55°C
10. Operating Voltage: +3.3V, +12V
11. OS Support: Windows, Linux, Solaris, VMware
12. Dimensions (WxDxH): 6.6 cm x 16.8 cm x 2.5 cm

Helpful Notes:
1. The LSI 9266-4i SGL RAID Controller supports up to 128 storage devices, making it ideal for large-scale storage solutions.
2. The 1GB DDR-III cache memory provides fast and efficient access to frequently used data.
3. The LSISAS2208 Dual-Core RAID on Chip (ROC) processor ensures reliable and high-performance RAID functionality.
