L46XBU1-00 - Opticon L-46X 2D Imager USB BarCode Scanner

Here are the technical specifications for the Opticon L-46X 2D Imager USB Barcode Scanner:

- Interface: USB HID, USB VCP, RS232
- Light source: Aiming: 617 nm LED; Illumination: White LED
- Scan rate: 60 fps
- Scan angle: Horizontal: 42.4°; Vertical: 33°
- Print contrast: 25% minimum reflectance difference
- Reading pitch angle: -45 to 0°, 0 to +45°
- Reading skew angle: -60 to -8°, +8 to +60°
- Reading tilt angle: 360°
- Depth of field: 40 - 220 mm (UPC/EAN 100%, PCS=90%)
- Supported symbologies: 1D: UPC/EAN/JAN, Codabar/NW-7, Code 39, Code 93, Code 128, GS1-128 (EAN-128), GS1 DataBar (RSS), IATA, Industrial 2of5, Interleaved 2of5, ISBN-ISMN-ISSN, Matrix 2of5, MSI/ Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey; 2D: Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code

Helpful notes:
- The Opticon L-46X 2D Imager USB Barcode Scanner is a versatile scanner that can read both 1D and 2D barcodes.
- With a scan rate of 60 fps, this scanner is fast and efficient.
- The scanner has a wide scan angle and reading tilt angle, making it easy to scan barcodes from different angles and positions.
