Sick OD1-B100H50I25 | Od Mini / Od Mini Prime Displacement Measurement Sensors

Technical Specs:
- Technology: Triangulation
- Measuring range: 100 mm
- Linearity max. ± 0.1 % of FSO
- Resolution: 0.01 mm
- Repeatability: 0.05 mm
- Light source: LED, 625 nm
- Laser class: 1 (IEC 60825-1:2014)
- Protection class: IP 67
- Operating temperature: -10...+50 °C
- Supply voltage: 10...30 V DC
- Output: 1x analog, 1x switching output (PNP/NPN selectable)
- Housing material: Aluminum
- Weight: 200 g

Helpful Notes:
- The OD Mini Prime version offers even higher accuracy and repeatability than the standard OD Mini.
- The IP67 protection class allows for use in harsh environments and washdown applications.
- The triangulation technology provides reliable and accurate displacement measurements.
