SUA2200XL - APC Smart-UPS XL2200VA 120V Tower/Rack Convertible Ups System

General Specifications:

• Output Power Capacity: 2200 VA (1600 watts).
• Input Voltage: 120 V.
• Output Voltage: 120 V.
• Topology: Line-Interactive, Double-Conversion On-Line.

Battery and Runtime:

• Battery Type: Maintenance-free, sealed lead-acid battery with suspended electrolyte.
• Typical Recharge Time: 3 hours.
• Replacement Battery Cartridge: RBC55.

Output Connections:

• NEMA 5-15R: 2.
• NEMA 5-20R: 6.
• NEMA L5-20R: 1.
• NEMA L5-20R: 1.

Communication and Management:

• Interface: DB-9 RS-232, SmartSlot, USB.
• Control Panel: Multi-function LCD status and control console.
• Audible Alarm: Alarm when on battery, distinctive low battery alarm, configurable delays.

Efficiency:

• Operating Mode: Line-interactive double-conversion on-line.
• Efficiency at Full Load: 88%.
• Efficiency at Half Load: 87%.

Environmental:

• Operating Temperature: 32-104°F (0-40°C).
• Storage Temperature: 5-113°F (-15-45°C).
• Operating Relative Humidity: 0-95% non-condensing.
• Storage Relative Humidity: 0-95% non-condensing.

Physical Dimensions:

• Height x Width x Depth: 3.4 x 17 x 27.3 inches (8.6 x 43.2 x 69.4 cm).
• Weight: 118.0 lbs (53.6 kg).

Battery and Runtime:

• Battery Type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte.
• Typical Recharge Time: 3 hours.
