T6RV9 - Dell PowerEdge R630 CTO Chassis

1. Processor: Supports up to 2 Intel Xeon E5-2600 v3 or v4 processors with up to 22 cores per processor.
2. Memory: 24 DIMM slots supporting DDR4 memory with a maximum capacity of 1.5TB.
3. Storage: Supports up to 8 x 2.5" SAS/SATA/SSD drives or up to 18 x 1.8" SAS/SATA/SSD drives.
4. RAID: Supports PERC S130, PERC H330, PERC H730, PERC H730P, and PERC H830 RAID controllers.
5. Networking: 4 x 1GbE LOM (LAN on Motherboard) ports, optional 2 x 10GbE LOM ports, and optional 2 x 10GbE SFP+ or Base-T NICs.
6. Expansion Slots: Up to 3 PCIe 3.0 expansion slots (1 x8 and 2 x16).
7. Power Supply: Dual redundant 750W or 1100W hot-plug power supplies.
8. Management: iDRAC8 with Lifecycle Controller for remote management.
9. Operating System: Supports Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, and VMware ESXi.
10. Form Factor: 1U rack-mountable chassis.
11. Dimensions: 19.08" x 1.68" x 28.75" (W x H x D).
12. Weight: Starting at 28.6 lbs.

Helpful notes:
1. The R630 is a great choice for virtualization, database, and high-performance computing workloads.
2. The iDRAC8 with Lifecycle Controller allows for easy deployment, configuration, and updates of the server.
3. The R630 is designed for easy serviceability with tool-less access to components and hot-swappable drives.
