X10DDW-I-B - Supermicro Dual LGA2011/ Intel C612/ DDR4/ SATA3/USB3.0/ V/2GbE/ Proprietary WIO Server Motherboard

1. Form Factor: Proprietary WIO Server Motherboard
2. CPU Socket Type: Dual LGA2011
3. Chipset: Intel C612
4. Memory Type: DDR4 ECC RDIMM/LRDIMM
5. Number of Memory Slots: 16x 288-pin DDR4 DIMM Slots
6. Maximum Memory Supported: Up to 2TB ECC 3DS LRDIMM, up to 2TB ECC RDIMM
7. SATA3 Ports: 10x SATA3 (6Gbps) Ports
8. USB 3.0 Ports: 4x USB 3.0 Ports (2 rear, 2 via header)
9. Network Connectivity: 2x 1GbE, 1x 10GBase-T
10. Expansion Slots: 3x PCI-E 3.0 x16, 2x PCI-E 3.0 x8
11. Integrated Graphics: ASPEED AST2400 BMC Graphics
12. Power Connectors: 1x 24-pin ATX Power Connector, 2x 8-pin ATX 12V Power Connectors

Notes:
1. This motherboard supports Intel Xeon E5-2600 v3/v4 processors.
2. The proprietary WIO design allows for flexible I/O options and expansion.
3. The ASPEED AST2400 BMC Graphics provides remote management capabilities.
