X10DRFR-B - Supermicro Dual LGA2011/ Intel C612/ DDR4/ SATA3/USB3.0/ V/2GbE/ Proprietary Server Motherboard

1. Form Factor: Proprietary
2. CPU Socket Type: Dual LGA 2011
3. Chipset: Intel C612
4. Memory Type: DDR4 ECC RDIMM/LRDIMM
5. Memory Slots: 16x 288-pin DIMM
6. Maximum Memory Supported: 1TB
7. Expansion Slots: 1x PCI-E 3.0 x16, 2x PCI-E 3.0 x8, 1x PCI-E 2.0 x4 (in x8), 1x PCI-E 2.0 x2 (in x8)
8. Storage: 10x SATA3 (6Gbps) ports, 1x M.2 slot
9. LAN: 2x 10GBase-T LAN ports
10. USB: 4x USB 3.0 ports (rear), 2x USB 2.0 ports (rear)
11. Audio: Realtek ALC888 7.1 HD Audio
12. Power Connectors: 1x 24-pin ATX main power connector, 2x 8-pin ATX 12V power connectors

Notes:
1. This motherboard supports Intel Xeon E5-2600 v3/v4 processors.
2. The M.2 slot supports M.2 SATA and M.2 NVMe SSDs.
3. The LAN ports support teaming and failover for increased network reliability.
