X10QBL-4 - SuperMicro X10QBL-4 Motherboard

1. Form factor: EATX
2. Processor: Intel Xeon processor E5-2600 v3/v4 family (up to 22 cores)
3. Chipset: Intel C612 chipset
4. Memory: 24x 288-pin DDR4 DIMM slots, up to 3TB ECC 3DS LRDIMM or RDIMM
5. Expansion slots: 4x PCIe 3.0 x16 slots, 2x PCIe 3.0 x8 slots, 1x PCIe 2.0 x4 (in x8) slot
6. Storage: 10x SATA3 (6Gbps) ports, 1x SATA DOM support, 2x NVMe ports
7. LAN: Dual 10GBase-T LAN ports, 1x dedicated IPMI LAN port
8. USB: 4x USB 3.0 ports (2 rear, 2 via header), 4x USB 2.0 ports (2 rear, 2 via header)
9. Audio: 7.1 HD Audio with optical S/PDIF
10. Power: Dual 24-pin ATX power connectors, 8-pin ATX 12V power connector
11. Management: IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
12. Operating temperature: 10°C to 35°C (50°F to 95°F)

Notes:
1. This motherboard is designed for high-performance computing and server applications.
2. The dual 10GBase-T LAN ports provide fast network connectivity for demanding workloads.
3. The 24 DIMM slots and support for up to 3TB of memory make this motherboard ideal for memory-intensive applications.
