X7SLA-L-O - Supermicro Atom 230/ Intel 945GC/ RAID/ V/GbE/ Flex ATX Motherboard

1. Processor: Intel Atom 230 processor
2. Chipset: Intel 945GC and ICH7
3. Memory: 2x 240-pin DDR2 DIMM slots, up to 4GB DDR2 533/400MHz SDRAM
4. Expansion Slots: 1x PCI, 1x Mini-PCIe (with SIM card support)
5. Storage: 4x SATA2 (3Gbps) ports with RAID 0, 1, 5, 10 support
6. Ethernet: 1x Intel 82573V Gigabit Ethernet Controller
7. Graphics: Intel Graphics Media Accelerator 950
8. Audio: Realtek ALC883 7.1 HD Audio
9. USB: 8x USB 2.0 ports (4 rear, 4 via headers)
10. Form Factor: Flex ATX (9.0" x 7.5", 228.6mm x 190.5mm)
11. Power: 24-pin ATX power connector
12. BIOS: 8Mb SPI Flash EEPROM with AMI BIOS

Notes:
1. The Mini-PCIe slot can be used for wireless networking or other expansion cards.
2. The motherboard supports Intel Hyper-Threading technology for improved performance.
3. The Realtek ALC883 audio codec supports high-definition audio with multi-channel output.
