X8DTG-QF-B - SuperMicro Dual LGA1366/ Intel 5520/ DDR3/ A/V/2GbE/ Proprietary Server Motherboard

1. Form Factor: Extended ATX (13.68" x 13.0")
2. CPU Support: Dual Intel Xeon 5500/5600 Series Processors (LGA1366 Socket)
3. Chipset: Intel 5520 (Tylersburg) Chipset
4. Memory Support: 12x 240-pin DDR3 DIMM Slots, Supports up to 192GB DDR3 ECC Registered Memory
5. Expansion Slots: 2x PCI-E 2.0 x16 Slots, 2x PCI-E 2.0 x8 Slots, 1x PCI-E 2.0 x4 (in x8) Slot, 1x PCI-E 2.0 x4 (in x8) Slot (Low Profile)
6. Storage: 6x SATA2 3.0 Gbps Ports, 2x SATA2 3.0 Gbps Ports via Add-on Card, 8x SAS Ports via Add-on Card (Optional)
7. Networking: 2x Gigabit Ethernet LAN Ports (Intel 82576)
8. USB Ports: 2x USB 2.0 Ports (2 rear), 4x USB 2.0 Ports (2 via header, 2 via add-on card)
9. Audio: Realtek ALC883 7.1 HD Audio
10. Video: Matrox G200eW Graphics
11. Management: IPMI 2.0 with Virtual Media over LAN and KVM-over-LAN support
12. Power Connectors: 1x 24-pin ATX Power Connector, 1x 8-pin ATX 12V Power Connector

Notes:
1. This motherboard supports both DDR3 ECC Registered and ECC Unbuffered memory, but they cannot be mixed.
2. The IPMI 2.0 feature allows for remote server management and monitoring, even when the server is powered off.
3. This motherboard is compatible with SuperMicro's proprietary server chassis, such as the SC747TQ-R1620B.
