X8DTT-HF - Supermicro / Dell System Board (Motherboard) for PowerEdge 6026

1. Form Factor: Extended ATX
2. Processor Socket: Dual LGA 1366
3. Supported Processors: Intel Xeon 5500/5600 series
4. Chipset: Intel 5520 (Tylersburg) chipset
5. Memory Slots: 18x 240-pin DDR3 DIMM slots
6. Maximum Memory Supported: 144GB
7. Memory Type Supported: DDR3 ECC Registered memory
8. Expansion Slots: 2x PCI-E 2.0 x16, 2x PCI-E 2.0 x8, 1x PCI-E 2.0 x4 (in x8)
9. Storage: 6x SATA2 3.0 Gb/s ports, 2x SAS ports (via LSI 1068E)
10. LAN: Dual-port Intel 82576 Gigabit Ethernet Controller
11. USB Ports: 2x USB 2.0 ports
12. Power Connectors: 2x 8-pin ATX 12V power connectors

Notes:
1. This motherboard is compatible with both Supermicro and Dell PowerEdge 6026 servers.
2. The LSI 1068E controller provides RAID 0, 1, 10 support for SAS drives.
3. The motherboard supports both 1U and 2U server chassis.
